MSDS – ESD Shielding Bags (Open Top & Zip Top)

ESD Shielding Bags – Open Top & Zip Top

Description

ESD Shielding Bags protect static-sensitive components during handling, storage, and transport. Constructed from multi-layer films (APET/CPP or APET/CPE), the silver-grey semi-transparent material provides a Faraday cage effect while allowing barcode scanning and visual identification.

Features

Surface resistance: 10⁹–10¹¹ Ω (customisable up to 10⁵–10¹¹ Ω).
Standard thickness: 75 µm (options: 60/70/80 µm).
Styles: Open Top, Zip Top; custom sizes/prints available.
RoHS / SGS statements available on request. Packing: 100 pcs / inner.

Technical Details

Material	APET / CPP or APET / CPE
Colour	Silver Grey (Semi-transparent)
Surface Resistance	10⁹–10¹¹ Ω (adjustable to 10⁵–10¹¹ Ω)
Standard Thickness	75 µm ± 10% (other options available)
Compliance	RoHS, SGS (supplier statements)
Packing	100 pcs per inner shield bag

Available Sizes

Open Top Type
P/N	Size (in)	Size (mm)
1602-01001	1.97×2.95	50×75
1602-01002	1.97×3.94	50×100
1602-01003	1.97×6.10	50×155
1602-01004	2.95×4.92	75×125
1602-01005	2.95×6.10	75×155
1602-01006	3.94×3.94	100×100
1602-01007	3.94×6.10	100×155
1602-01008	3.94×8.07	100×205
1602-01009	3.94×18.11	100×460
1602-01010	3.94×24.02	100×610
1602-01011	3.94×25.98	100×660
1602-01012	3.94×29.92	100×760
1602-01013	4.92×6.10	125×155
1602-01014	4.92×6.89	125×175
1602-01015	4.92×7.87	125×200
1602-01016	4.92×8.07	125×205
1602-01017	4.92×9.06	125×230
1602-01018	6.10×9.06	155×230
1602-01019	5.91×7.87	150×200
1602-01020	5.91×9.06	150×230
1602-01021	5.91×9.84	150×250
1602-01022	5.91×10.63	150×270
1602-01023	5.91×11.81	150×300
1602-01024	5.91×12.60	150×320
1602-01025	5.91×13.78	150×350

Open Top Type
P/N	Size (in)	Size (mm)
1602-01026	5.91×17.72	150×450
1602-01027	6.30×7.87	160×200
1602-01028	6.30×9.06	160×230
1602-01029	6.30×9.84	160×250
1602-01030	6.30×10.63	160×270
1602-01031	6.30×11.81	160×300
1602-01032	6.30×12.60	160×320
1602-01033	6.30×13.78	160×350
1602-01034	7.09×9.84	180×250
1602-01035	7.09×10.63	180×270
1602-01036	7.09×11.81	180×300
1602-01037	7.09×12.60	180×320
1602-01038	7.09×13.78	180×350
1602-01039	7.48×11.02	190×280
1602-01040	7.87×9.84	200×250
1602-01041	7.87×11.02	200×280
1602-01042	7.87×11.81	200×300
1602-01043	7.87×12.60	200×320
1602-01044	7.87×13.78	200×350
1602-01045	7.87×14.96	200×380
1602-01046	7.87×15.75	200×400
1602-01047	9.45×11.02	240×280
1602-01048	9.45×11.81	240×300
1602-01049	9.45×12.60	240×320
1602-01050	9.45×13.78	240×350
1602-01051	9.45×14.96	240×380
1602-01052	9.45×15.75	240×400

Open Top Type
P/N	Size (in)	Size (mm)
1602-01053	11.02×13.78	280×350
1602-01054	11.02×14.96	280×380
1602-01055	11.02×15.75	280×400
1602-01056	11.81×13.78	300×350
1602-01057	11.81×14.96	300×380
1602-01058	11.81×15.75	300×400
1602-01059	11.81×17.72	300×450
1602-01060	13.78×15.75	350×400
1602-01061	13.78×17.32	350×440
1602-01062	14.17×17.72	360×450
1602-01063	15.94×20.08	405×510
1602-01064	15.94×24.02	405×610
1602-01065	15.94×25.98	405×660
1602-01066	18.11×18.11	460×460
1602-01067	18.11×20.08	460×510
1602-01068	18.11×24.02	460×610
1602-01069	18.11×25.98	460×660
1602-01070	18.11×29.92	460×760
1602-01071	20.08×20.08	510×510
1602-01072	20.08×24.02	510×610
1602-01073	20.08×25.98	510×660
1602-01074	22.05×24.02	560×610
1602-01075	24.02×24.02	610×610
1602-01076	24.02×29.92	610×760

Zip Top Type
P/N	Size (in)	Size (mm)
1602-01077	1.97×2.95	50×75
1602-01078	1.97×3.94	50×100
1602-01079	1.97×6.10	50×155
1602-01080	2.95×4.92	75×125
1602-01081	2.95×6.10	75×155
1602-01082	3.94×3.94	100×100
1602-01083	3.94×6.10	100×155
1602-01084	3.94×8.07	100×205
1602-01085	3.94×18.11	100×460
1602-01086	3.94×24.02	100×610
1602-01087	3.94×25.98	100×660
1602-01088	3.94×29.92	100×760
1602-01089	4.92×6.10	125×155
1602-01090	4.92×6.89	125×175
1602-01091	4.92×7.87	125×200
1602-01092	4.92×8.07	125×205
1602-01093	4.92×9.06	125×230
1602-01094	6.10×9.06	155×230
1602-01095	5.91×7.87	150×200
1602-01096	5.91×9.06	150×230
1602-01097	5.91×9.84	150×250
1602-01098	5.91×10.63	150×270
1602-01099	5.91×11.81	150×300
1602-01100	5.91×12.60	150×320
1602-01101	5.91×13.78	150×350

Zip Top Type
P/N	Size (in)	Size (mm)
1602-01102	5.91×17.72	150×450
1602-01103	6.30×7.87	160×200
1602-01104	6.30×9.06	160×230
1602-01105	6.30×9.84	160×250
1602-01106	6.30×10.63	160×270
1602-01107	6.30×11.81	160×300
1602-01108	6.30×12.60	160×320
1602-01109	6.30×13.78	160×350
1602-01110	7.09×9.84	180×250
1602-01111	7.09×10.63	180×270
1602-01112	7.09×11.81	180×300
1602-01113	7.09×12.60	180×320
1602-01114	7.09×13.78	180×350
1602-01115	7.48×11.02	190×280
1602-01116	7.87×9.84	200×250
1602-01117	7.87×11.02	200×280
1602-01118	7.87×11.81	200×300
1602-01119	7.87×12.60	200×320
1602-01120	7.87×13.78	200×350
1602-01121	7.87×14.96	200×380
1602-01122	7.87×15.75	200×400
1602-01123	9.45×11.02	240×280
1602-01124	9.45×11.81	240×300
1602-01125	9.45×12.60	240×320
1602-01126	9.45×13.78	240×350
1602-01127	9.45×14.96	240×380
1602-01128	9.45×15.75	240×400

Zip Top Type
P/N	Size (in)	Size (mm)
1602-01129	11.02×13.78	280×350
1602-01130	11.02×14.96	280×380
1602-01131	11.02×15.75	280×400
1602-01132	11.81×13.78	300×350
1602-01133	11.81×14.96	300×380
1602-01134	11.81×15.75	300×400
1602-01135	11.81×17.72	300×450
1602-01136	13.78×15.75	350×400
1602-01137	13.78×17.32	350×440
1602-01138	14.17×17.72	360×450
1602-01139	15.94×20.08	405×510
1602-01140	15.94×24.02	405×610
1602-01141	15.94×25.98	405×660
1602-01142	18.11×18.11	460×460
1602-01143	18.11×20.08	460×510
1602-01144	18.11×24.02	460×610
1602-01145	18.11×25.98	460×660
1602-01146	18.11×29.92	460×760
1602-01147	20.08×20.08	510×510
1602-01148	20.08×24.02	510×610
1602-01149	20.08×25.98	510×660
1602-01150	22.05×24.02	560×610
1602-01151	24.02×24.02	610×610
1602-01152	24.02×29.92	610×760

IMPORTANT: This data sheet and its contents (the “Information”) are owned by Sucatec or licensed to it. The Information is provided solely for informational purposes related to the described products. No license or right of use is granted, and no intellectual property rights are transferred. The Information is subject to change without notice and supersedes all prior data sheets. While believed accurate, Sucatec assumes no responsibility for its completeness or any reliance placed on it. Users must verify suitability for their specific purposes. Liability for any loss or damage resulting from use or reliance is excluded. © 2025 Sucatec.

Document No.: MSDS-1602-ESD-SHIELD

Revision: 01

Date of Issue: 26 October 2025

This is a controlled document. Uncontrolled if printed or stored outside the official Sucatec document system.
