Datasheet – Self-Clinching Pins

Self-Clinching Pins

Description

Self-clinching pins are unthreaded pin components designed to be permanently installed into thin sheet metal. Once pressed into a correctly prepared hole, the clinching feature provides strong retention and resistance to push-out, helping create a durable locating, spacing, or alignment feature without welding or secondary operations.

Technical Dimensions

Thread Size	Type	Material	Finish	Sheet Min.	Hole Diameter	B	D	L	X	CL to Edge Min.
Unthreaded				0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	1.25 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.25 (±0.015)	0.075	0.19
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.25 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.25 (±0.015)	0.075	0.19
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.25 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.312 (±0.015)	0.075	0.19
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.312 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.312 (±0.015)	0.075	0.19
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.312 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.375 (±0.015)	0.075	0.19
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.375 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.375 (±0.015)	0.075	0.19
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.375 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.5 (±0.015)	0.075	0.19
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.5 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.5 (±0.015)	0.075	0.19
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.5 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.625 (±0.015)	0.075	0.19
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.625 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.625 (±0.015)	0.075	0.19
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.085 (+0.003 / -0.000)	0.15 (±0.015)	0.073 (±0.002)	0.625 (±0.015)	0.075	0.19
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.099 (+0.003 / -0.000)	0.16 (±0.015)	0.084 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.111 (+0.003 / -0.000)	0.18 (±0.015)	0.094 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.25 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.312 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.375 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.5 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.625 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.118 (+0.003 / -0.000)	0.18 (±0.015)	0.103 (±0.002)	0.75 (±0.015)	0.085	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.25 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.25 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.25 (±0.015)	0.09	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.25 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.312 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.312 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.312 (±0.015)	0.09	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.312 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.375 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.375 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.375 (±0.015)	0.09	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.375 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.5 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.5 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.5 (±0.015)	0.09	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.5 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.625 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.625 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.625 (±0.015)	0.09	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.625 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.75 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.75 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.75 (±0.015)	0.09	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.125 (+0.003 / -0.000)	0.19 (±0.015)	0.106 (±0.002)	0.75 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	0.875 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 7076-T6		0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	0.875 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	0.875 (±0.015)	0.09	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	0.875 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	1 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 7076-T6		0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	1 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	1 (±0.015)	0.09	0.22
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	1 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	1.25 (±0.015)	0.09	0.22
Unthreaded	Unified	Aluminum 7076-T6		0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	1.25 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.125 (+0.003)	0.19 (±0.015)	0.106 (±0.002)	1.25 (±0.015)	0.09	0.22
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.312 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.312 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.312 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.312 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.375 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.375 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.375 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.375 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.5 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.5 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.5 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.5 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.625 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.625 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.625 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.625 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.75 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.75 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.75 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.75 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.875 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.875 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.875 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	0.875 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	1 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	1 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	1 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	1 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	1.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	1.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	1.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.116 (±0.002)	1.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.312 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.312 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.312 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.312 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.375 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.375 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.375 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.375 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.5 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.5 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.5 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.5 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.625 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.625 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.625 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.625 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.75 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.75 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.75 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.75 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.875 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.875 (±0.015)	0.09
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.875 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	0.875 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	1 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	1 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	1 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	1 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	1.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	1.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	1.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.137 (+0.003 / -0.000)	0.21 (±0.015)	0.12 (±0.002)	1.25 (±0.015)	0.09	0.25
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.312 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.312 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.312 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.312 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.375 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.375 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.375 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.375 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.625 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.625 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.625 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.625 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.75 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.75 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.75 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.75 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.875 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.875 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.875 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	0.875 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.157 (+0.003 / -0.000)	0.23 (±0.015)	0.137 (±0.002)	1.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.312 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.312 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.312 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.312 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.375 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.375 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.375 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.375 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.625 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.625 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.625 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.625 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.75 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.75 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.75 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.75 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.875 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.875 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.875 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	0.875 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1.25 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.163 (+0.003 / -0.000)	0.24 (±0.015)	0.141 (±0.002)	1.5 (±0.015)	0.09	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.16 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.189 (+0.003 / -0.000)	0.26 (±0.015)	0.167 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.312 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.375 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.625 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.75 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	0.875 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1.25 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Aluminum 2024-T4		0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.04	0.197 (+0.003 / -0.000)	0.26 (±0.015)	0.173 (±0.002)	1.5 (±0.015)	0.1	0.28
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.375 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.375 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.375 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.375 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1.25 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1.25 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1.25 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1.25 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.236 (+0.003 / -0.000)	0.32 (±0.015)	0.207 (±0.002)	1.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1.25 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1.25 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1.25 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1.25 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.215 (±0.002)	1.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.5 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.625 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.75 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	0.875 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Aluminum 2024-T4		0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.062	0.25 (+0.003 / -0.000)	0.34 (±0.015)	0.223 (±0.002)	1 (±0.015)	0.135	0.31
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.625 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.625 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.625 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.625 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.75 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.75 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.75 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.75 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.875 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.875 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.875 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	0.875 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1.25 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1.25 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1.25 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1.25 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.273 (±0.002)	1.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.5 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.625 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.625 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.625 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.625 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.75 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.75 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.75 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.75 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.875 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.875 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.875 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	0.875 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	1 (±0.015)	0.16	0.38
Unthreaded	Unified	Aluminum 2024-T4		0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	1 (±0.015)	0.16	0.38
Unthreaded	Unified	Steel Non Heat Treated	Zinc Clear	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	1 (±0.015)	0.16	0.38
Unthreaded	Unified	Stainless Steel 300 Series	Passivated	0.093	0.312 (+0.003 / -0.000)	0.38 (±0.015)	0.281 (±0.002)	1 (±0.015)	0.16	0.38
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	6 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	6 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	6 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	6 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	8 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	8 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	8 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	8 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	10 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	10 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	10 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	10 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	12 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	12 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	12 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	12 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	15 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	15 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	15 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	15 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	18 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	18 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	18 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	18 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	20 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	20 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	20 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	20 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	25 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	25 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	25 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	25 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	30 (±0.4)	2.3	6.4
Unthreaded	Metric	Aluminum 2024-T4		1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	30 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	30 (±0.4)	2.3	6.4
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	3.5 (+0.080 / -0.000)	5.3 (±0.4)	3 (±0.05)	30 (±0.4)	2.3	6.4
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	8 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	8 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	8 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	8 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	10 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	10 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	10 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	10 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	12 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	12 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	12 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	12 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	15 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	15 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	15 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	15 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	18 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	18 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	18 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	18 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	20 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	20 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	20 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	20 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	25 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	25 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	25 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	25 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	30 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	30 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	30 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	30 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	35 (±0.4)	2.3	7.1
Unthreaded	Metric	Aluminum 2024-T4		1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	35 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	35 (±0.4)	2.3	7.1
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	4.1 (+0.080 / -0.000)	6 (±0.4)	4 (±0.05)	35 (±0.4)	2.3	7.1
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	8 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	8 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	8 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	8 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	10 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	10 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	10 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	10 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	12 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	12 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	12 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	12 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	15 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	15 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	15 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	15 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	18 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	18 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	18 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	18 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	20 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	20 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	20 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	20 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	25 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	25 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	25 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	25 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	30 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	30 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	30 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	30 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	35 (±0.4)	2.55	7.6
Unthreaded	Metric	Aluminum 2024-T4		1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	35 (±0.4)	2.55	7.6
Unthreaded	Metric	Steel Non Heat Treated	Zinc Clear	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	35 (±0.4)	2.55	7.6
Unthreaded	Metric	Stainless Steel 300 Series	Passivated	1	5.5 (+0.080 / -0.000)	7.5 (±0.4)	5 (±0.05)	35 (±0.4)	2.55	7.6

GET IN TOUCH
