MSDS / Technical Datasheet – Self-Clinching Flush Nuts

MSDS / Technical Datasheet – Self-Clinching Flush Nuts

Self-Clinching Flush Nut
Product type: Metal fastener article (self-clinching flush nut).
Hazard status: Solid article. Not classified as hazardous in normal use/handling. Machining, grinding, or welding may generate metal dust or fumes.

Description

Self-clinching flush nuts designed for permanent installation into thin sheet materials, providing a flush-threaded fastening point in panels, chassis, and enclosures.

Materials & Finish Options

  • Material: Stainless steel (solid fastener)
  • Finish: Passivated

Hazard Information

Solid article. Not expected to present a chemical hazard under normal conditions of use. Mechanical hazards may include sharp edges and pinch points during installation. Processing (cutting/grinding/welding) may generate airborne particulate or fumes; use appropriate controls and PPE.

Technical Data – Sizes & Installation Dimensions

Search filters the entire table live.
Units: Unified (Imperial) dimensions are in inches. Metric dimensions are in mm. Tolerances (where provided) are shown in brackets.
Thread size Type Material Finish Sheet min. Hole diameter (B max.) D max. H nom. CL to edge (min.)
#2-56UnifiedStainless steelPassivated0.060.172 (+0.003 / -0.0)0.1710.1880.23
#2-56UnifiedStainless steelPassivated0.0910.172 (+0.003 / -0.0)0.090.1710.188
#4-40UnifiedStainless steelPassivated0.060.172 (+0.003 / -0.0)0.060.1710.188
#4-40UnifiedStainless steelPassivated0.0910.172 (+0.003 / -0.0)0.090.1710.188
#6-32UnifiedStainless steelPassivated0.060.213 (+0.003 / -0.0)0.060.2120.25
#6-32UnifiedStainless steelPassivated0.0910.213 (+0.003 / -0.0)0.090.2120.25
#8-32UnifiedStainless steelPassivated0.060.29 (+0.003 / -0.0)0.060.2890.312
#8-32UnifiedStainless steelPassivated0.0910.29 (+0.003 / -0.0)0.090.2890.312
#10-24UnifiedStainless steelPassivated0.060.312 (+0.003 / -0.0)0.060.3110.343
#10-24UnifiedStainless steelPassivated0.0910.312 (+0.003 / -0.0)0.090.3110.343
#10-32UnifiedStainless steelPassivated0.060.312 (+0.003 / -0.0)0.060.3110.343
#10-32UnifiedStainless steelPassivated0.0910.312 (+0.003 / -0.0)0.090.3110.343
1/4-20UnifiedStainless steelPassivated0.1250.344 (+0.003 / -0.0)0.120.3430.375
1/4-20UnifiedStainless steelPassivated0.1560.344 (+0.003 / -0.0)0.1510.3430.375
1/4-20UnifiedStainless steelPassivated0.1870.344 (+0.003 / -0.0)0.1820.3430.375
1/4-28UnifiedStainless steelPassivated0.1250.344 (+0.003 / -0.0)0.120.3430.375
1/4-28UnifiedStainless steelPassivated0.1560.344 (+0.003 / -0.0)0.1510.3430.375
1/4-28UnifiedStainless steelPassivated0.1870.344 (+0.003 / -0.0)0.1820.3430.375
M2 x 0.4MetricStainless steelPassivated1.534.37 (+0.08 / -0.0)1.534.354.8
M2 x 0.4MetricStainless steelPassivated2.324.37 (+0.08 / -0.0)2.34.354.8
M2.5 x 0.45MetricStainless steelPassivated1.534.37 (+0.08 / -0.0)1.534.354.8
M2.5 x 0.45MetricStainless steelPassivated2.324.37 (+0.08 / -0.0)2.34.354.8
M3 x 0.5MetricStainless steelPassivated1.534.37 (+0.08 / -0.0)1.534.354.8
M3 x 0.5MetricStainless steelPassivated2.324.37 (+0.08 / -0.0)2.34.354.8
M3.5 x 0.6MetricStainless steelPassivated1.535.4 (+0.08 / -0.0)1.535.356.4
M3.5 x 0.6MetricStainless steelPassivated2.325.4 (+0.08 / -0.0)2.35.356.4
M4 x 0.7MetricStainless steelPassivated1.537.37 (+0.08 / -0.0)1.537.357.9
M4 x 0.7MetricStainless steelPassivated2.327.37 (+0.08 / -0.0)2.37.357.9
M5 x 0.8MetricStainless steelPassivated1.537.92 (+0.08 / -0.0)1.537.98.7
M5 x 0.8MetricStainless steelPassivated2.327.92 (+0.08 / -0.0)2.37.98.7
M6 x 1.0MetricStainless steelPassivated3.188.74 (+0.08 / -0.0)3.058.729.5
M6 x 1.0MetricStainless steelPassivated3.968.74 (+0.08 / -0.0)3.848.729.5
M6 x 1.0MetricStainless steelPassivated4.758.74 (+0.08 / -0.0)4.638.729.5

Handling, PPE & First Aid

  • Normal handling: No special PPE required beyond standard industrial practice.
  • During machining/grinding/welding: Safety glasses (or face shield), suitable gloves, and local extraction; use respiratory protection if airborne dust is present.
  • Eye contact (dust/particles): Rinse cautiously with water for several minutes. Seek medical attention if irritation persists.
  • Skin contact: Wash with soap and water. Treat cuts/abrasions as required.
  • Inhalation (dust/fume): Move to fresh air. Seek medical advice if symptoms persist.

Disposal

Recycle as scrap metal where facilities exist. Collect machining debris and dispose in accordance with site requirements and local regulations.

IMPORTANT: This MSDS / Technical Datasheet is provided for informational purposes for the product as supplied (solid article). Cutting, grinding, welding or machining may create hazardous dust/fume; ensure appropriate workplace controls are used.
